MARATHON MOTORS 145TTGN6536 Hazardous Location Motor 1-1/2 Hp 1755 Rpm 145tc | AC8FAR 39P310 / C362A

LEESON 145TTGN6536 C362A / 145TTGN6536AA Explosion Proof Motor, 1.50/1 HP, 3 Phase, 60/50 Hz, 230/460 and 190/380 V, 1800 RPM

Item: AC8FAR Model: 145TTGN6536Cross Ref: 39P310 / C362A / 145TTGN6536AA
In Stock

Get it by Tuesday, Dec 31

€1,200.22 /unit
Add To Cart
Request a Quote

Payment Options Available

Delivery Options Available

Product Specifications:

ItemHazardous Location Motor
BearingsBall
DutyContinuous
Efficiency GroupNema Premium
EnclosureTotally Enclosed Fan-Cooled
Frame145Tc
Frame MaterialCast Iron
Full Load Amps4.7-4.6/2.3, 4.2/2.1
Hazardous Location Class1 D / 2 F,G
HP1.5
Hz50/60
Insulation ClassF
Length Less Shaft13.125"
Max. Ambient Temp.40 Degrees C
Motor ApplicationHazardous Locations
Motor Design3-Phase
Motor Enclosure DesignTotally Enclosed Fan-Cooled
Motor Mounting TypeRigid Base
Motor Shaft DesignKeyed
Motor Shaft RotationCW/CCW
Motor Thermal ProtectionT-stat
Motor Type3-Phase
MountingRigid
Nameplate RPM1755
NEMA DesignB
Nominal Efficiency86.5%
Overall Length15.25"
Phase3
RotationCW/CCW
RPM Range1701-1800
Service Factor1.15
Shaft Dia.7/8"
Shaft Length2.125"
Temp. CodeT3B
Thermal ProtectionT Stat
Voltage208-230/460

Shipping Info:

Ship weight (kg) 36
Ship height (cm)23.83
Ship length (cm)40.16
Ship width (cm)36.35
HS code8501524000
Country of OriginMX

Product Details:

    • Supersedes Marathon - C362 / 145TTGN4032

Product Variants

ProductModelFrameFull Load AmpsHPNameplate RPMNominal EfficiencyPrice
MARATHON MOTORS 143TTGN6551 Hazardous Location Motor 1 Hp 1735 Rpm 208-230/460v | AC8FAQ 39P309 / C361A 143TTGN6551143TC3-3/1.5, 2.8/1.41173585.5%€1,133.61
MARATHON MOTORS 145TTGN6549 Hazardous Location Motor 2 Hp 1755 Rpm 208-230/460v | AC8FAT 39P311 / C363A 145TTGN6549145TC6.2-6/3, 5.6/2.82175586.5%€1,261.33
