MARATHON MOTORS 056T17D5329 G122 HVAC Motor 50-60 Hertz | AJ2LKN G122

LEESON 056T17D5329 G122 / 56T17D5329B Fan/Blower Motor, 1.50/1 HP, 3 Phase, 60/50 Hz, 208-230/460 and 190/380V, 1800 RPM

Item: AJ2LKN Model: 056T17D5329Cross Ref: 490T75 / G122 / 56T17D5329B
In Stock

Get it by Friday, May 23

€548.83 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemHVAC Motor
Ambient Temp.40°C
AssemblyF1 Only
Bearing TypeBall
Body Dia.6 1/2"
Conduit Box PositionF1 Only
DesignB
Duty CycleContinuous
EfficiencyNot Applicable
Enclosure TypeDripproof
Frame56
Frequency60 Hz
Full Load Amps4.8/2.4A
Full Load Efficiency80%
Hp1 1/2 hp
Insulation ClassClass B
Length Less Shaft9 1/2"
Max. Ambient Temp.40°C
Motor ApplicationHVAC/R
Motor Enclosure DesignDripproof
Motor Frame MaterialSteel
Motor Mounting PositionHorizontal
Motor Mounting TypeResilient Base
Motor Shaft DesignKeyed
Motor Shaft RotationCW/CCW
Motor Sub ApplicationBelt Drive Fan/Blower
Motor Thermal ProtectionNo
Motor TypeSquirrel Cage Induction Run
Mounting TypeResilient Base
Nema DesignB
Number Of Speeds1
Overall Length11 3/8"
Phase3
Power1.12 kW
Resilient Ring Dia.2 1/2"
Ring To Ring Center9.062"
Rpm Range1701-1800 RPM
Service Factor1.15
Shaft Dia.5/8"
Shaft Length1.91"
Shaft OrientationHorizontal
Usable @ 200vNo
Usable @ 208vYes
Voltage208-230/460V AC
Warranty1 yr.

Shipping Info:

Ship weight (kg) 13.05
Ship height (cm)19.69
Ship length (cm)33.66
Ship width (cm)20.32
HS code8501524000
Country of OriginMX

Product Details:

    • Starting Type: ACROSS THE LINE
    • KVA Code: K
    • Drive End Bearing: BALL
    • IP Code: 22
    • Opposite End Bearing: BALL
    • Drive End Bearing Size: 6203
    • Opposite End Bearing Size: 6203

Product Variants

ProductModelVoltageFrameHpMotor Mounting PositionShaft LengthMotor Mounting TypeMotor Enclosure DesignMotor Thermal ProtectionPrice
MARATHON MOTORS 5K49PN4088X K1415 HVAC Motor | AJ2KWH K1415 5K49PN4088X200-230/460V AC56H1 1/2 hpAll Angle1 22/25"CradleOpen DripproofNo€622.91
MARATHON MOTORS 5K49UN4086X K1418 HVAC Motor | AJ2KYZ K1418 5K49UN4086X208-230/460V AC56H2 hpAll Angle1 22/25"CradleOpen DripproofNo€679.08
MARATHON MOTORS 5K46KN4085 K277 HVAC Motor | AJ2KZR K277 5K46KN4085208-230/460V AC563/4 hpAll Angle1 22/25"CradleOpen DripproofNo€483.39
MARATHON MOTORS 056T17D5350 G145 HVAC Motor 50-60 Hertz | AJ2LGG G145 056T17D5350208-230/460V AC56HZ3 hpHorizontal2 7/25"---€755.64
MARATHON MOTORS 056T17D2104 G106 HVAC Motor 50-60 Hertz | AJ2LJB G106 056T17D2104208-230/460V561/3 hpHorizontal1.97"Resilient BaseDripproofAutomatic€461.16
MARATHON MOTORS 5K49PN3052 K280 HVAC Motor | AJ2LJM K280 5K49PN3052460V AC563 1/4 hpAll Angle1 22/25"Rigid BaseDripproofNo€748.84
MARATHON MOTORS 056T17D2101 G100 HVAC Motor 50-60 Hertz | AJ2LJP G100 056T17D2101208-230/460V AC56------€571.67
